TBS2631 8 channel HD Live Stream IPTV Encoder

Special Order – Contact Us for info

Compare
SKU: TBS2631 Category:

Description

TBS2631 8-Channel HDMI Encoder can realize 8-channel HDMI collection, real-time HD encoding and RTMP forwarding. Compared with current mainstream coding machine solution, its coding efficiency increased by 50%, power consumption drop 65%, 80% reduction in volume. It is an innovative network HD broadcast coding machine.

TBS2631 highly integrated hardware and software. It is convenience for customers release RTPM streams into IPTV streaming media server.

TBS2631 will greatly save the network traffic, electricity and space utilization rate, improve the live operator front-end equipment reliability, reduce operating costs and entry barriers

Features:

  • 8 channel HDMI capture, real-time HD encoding
  • RTPM streams into IPTV streaming media server
  • Support 720P resolution
  • Support multiple equipments display at the same time on a computer
  • 1U chassis , low power consumption, less than 70W
  • Greatly save on network traffic, electricity and space usage
  • Add/Remove water-mark dynamically
  • Sample software UI

Application:

  • IPTV
  • Video Conference
  • Live Broadcast
  • Teaching/Campus Broadcast

Specification:

Input Interface 8 x HDMI
Output RJ45 100/1000Mbps
HD format 1280*720p50/60
Protocol RTMP
AC in 110/220
AC rate 50/60Hz
Power consumption Less than 70W
Encoding quality
Excellent 1.3Mbps
Good 1.0Mbps
Fair 800Kbps
Poor 600Kbps
OS Windows7
Size 1U chassis
Weight 4kg
